SUITABLE FOR:

HILUX 7 Chassis (N1, N2) 02.05 -
2.0 (TGN15) 05.05 - 02.16 100 136 1998 4 1TR-FE

HILUX 7 Pick-up (N1, N2, N3) 08.04 - 02.16
2.0 VVT-i (TGN10, TGN15, TGN16) 05.05 - 02.16 100 136 1998 4 1TR-FE
2.7 VVT-i 05.05 - 02.16 118 160 2694 4 2TR-FE
2.7 VVT-i 4WD 05.05 - 10.09 118 160 2694 4 2TR-FE
4.0 V6 VVT-i 10.08 - 02.16 175 238 3956 6 1GR-FE
4.0 V6 VVT-i 4WD 04.05 - 02.16 175 238 3956 6 1GR-FE
2.5 D-4D (KUN15, KUN10) 05.05 - 02.16 75 102 2494 4 2KD-FTV
2.5 D-4D 4WD (KUN25) 05.05 - 02.16 75 102 2494 4 2KD-FTV
2.5 D-4D (KUN15, KUN35) 10.12 - 02.16 106 144 2494 4 2KD-FTV
3.0 D-4D (KUN16, KUN36) 05.05 - 02.16 120 163 2982 4 1KD-FTV
3.0 D-4D 4WD (KUN26) 05.05 - 02.16 120 163 2982 4 1KD-FTV

HILUX 8 Chassis (N1) 05.15 -
2.4 GD-6 (GUN112, GUN122, GUN135, GUN125) 02.16 - 110 150 2393 4 2GD-FTV

HILUX 8 Pick-up (N1) 05.15 -
2.4 GD-6 (GUN112, GUN122, GUN135, GUN120) 02.16 - 110 150 2393 4 2GD-FTV
2.4 GD-6 4WD (GUN125) 02.16 - 110 150 2393 4 2GD-FTV

SPECS:
Outer Diameter [mm] 77,00 mm
Inner Diameter [mm] 43,00 mm
Width [mm] 41,50 mm
Fitting Position Front Axle
Width 1 [mm] 45,5 mm

PICTURES FOR ILLUSTRATION PURPOSES ONLY.
